SeerRay-Lab/Qwen2.5-VL-7B-HyperClick

HyperClick-7B

Paper · Code · 3B model · 7B model

Overview

HyperClick grounds natural-language instructions in GUI screenshots and predicts a click point together with an explicit confidence score. This repository contains the 7B checkpoint, based on Qwen2.5-VL-7B-Instruct, with full model weights in Safetensors format.

The training framework combines supervised fine-tuning with reinforcement fine-tuning. Its rewards check output format, grounding correctness, and confidence alignment using a truncated Gaussian spatial target and the Brier score. See the training code for details.

Reported results

Grounding accuracy (%) from the project evaluation table. These are the project's reported results, not a new evaluation of the uploaded files.

Model	ScreenSpot	ScreenSpot-v2	ScreenSpot-Pro	MMBench-GUI	UI-I2E-Bench	CAGUI	UI-Vision
HyperClick-3B	88.5	90.6	41.3	71.4	71.8	81.0	19.6
HyperClick-7B	91.5	93.7	48.2	79.6	76.5	82.9	25.7

Quick start

The example below uses Transformers on a CUDA GPU. Install PyTorch for your CUDA environment, then install the inference dependencies:

pip install "transformers==4.49.0" "accelerate==1.10.0" "qwen-vl-utils==0.0.11" pillow

Replace screenshot.png and the instruction with your own input. The prompt follows the HyperClick training template.

import torch
from PIL import Image
from transformers import AutoProcessor, Qwen2_5_VLForConditionalGeneration
from qwen_vl_utils import process_vision_info

model_id = "SeerRay-Lab/Qwen2.5-VL-7B-HyperClick"
model = Qwen2_5_VLForConditionalGeneration.from_pretrained(
    model_id, torch_dtype=torch.bfloat16, device_map="auto"
).eval()
processor = AutoProcessor.from_pretrained(
    model_id, min_pixels=3136, max_pixels=4390400, use_fast=False
)

screenshot = Image.open("screenshot.png").convert("RGB")
instruction = "Click the search button"
messages = [dict(role="user", content=[
    dict(type="image", image=screenshot, min_pixels=3136, max_pixels=4390400),
    dict(type="text", text=(
        f'Point to the element related to the instruction "{instruction}" '
        'on the screenshot with your confidence.'
    )),
])]
prompt = processor.apply_chat_template(
    messages, tokenize=False, add_generation_prompt=True
)
images, _ = process_vision_info(messages)
inputs = processor(text=[prompt], images=images, return_tensors="pt").to(model.device)
with torch.inference_mode():
    generated = model.generate(**inputs, max_new_tokens=128, do_sample=False)
answer = processor.batch_decode(
    generated[:, inputs.input_ids.shape[1]:], skip_special_tokens=True
)[0]
print(answer)

# Dimensions of the image coordinate space used by the model.
patch_size = processor.image_processor.patch_size
_, grid_h, grid_w = inputs.image_grid_thw[0].tolist()
input_width, input_height = grid_w * patch_size, grid_h * patch_size
print("Model image size:", input_width, input_height)

Output format and coordinates

The expected output format is:

<point>[x,y]</point><confidence>conf</confidence>

x and y are pixel coordinates in the processed image; conf is a confidence estimate between 0 and 1. To map a predicted point back to the original screenshot, use:

# x and y are parsed from the model response.
x_original = x * screenshot.width / input_width
y_original = y * screenshot.height / input_height

Image resizing affects the coordinate system. Validate the response format and point bounds before using a prediction. Confidence is a learned estimate and can be incorrect, especially for unfamiliar interfaces or ambiguous instructions.

Training

The GitHub repository provides training setup, example annotation formats, and the reinforcement fine-tuning entry points:

bash src/open-r1-multimodal/run_hyperclick_7b.sh

License

This repository retains its Apache-2.0 license designation. See the base model license.

Citation

The latest arXiv version is titled Enhancing Trustworthy GUI Grounding via Self-Critiqued Reinforcement Learning.

@misc{zhang2025hyperclick,
  title={Enhancing Trustworthy GUI Grounding via Self-Critiqued Reinforcement Learning},
  author={Shaojie Zhang and Pei Fu and Ruoceng Zhang and Jiahui Yang and Anan Du and Xiuwen Xi and Shaokang Wang and Ying Huang and Bin Qin and Zhenbo Luo and Jian Luan},
  year={2025},
  eprint={2510.27266},
  archivePrefix={arXiv},
  primaryClass={cs.CV},
  url={https://arxiv.org/abs/2510.27266}
}
