Solitito — guitar chord and note recognition
Recognition models for Solitito, a real-time guitar trainer written in Rust. Code, the trainer and documentation are in the GitHub repository; this repository holds the binary artifacts the app needs.
| file | |
|---|---|
best_model_v2_take6_chords.onnx |
the recognition model: what is sounding, the root and the chord quality, 29 MB |
short_onset_masking_v2.onnx |
the strike model: which pitch class was just struck, 1 MB |
dsp_weights.json |
pseudo-CQT kernel in sparse format, 2 MB |
The recognition model
Takes 48 frames of features (144 CQT bins + 12 chroma + 12 bass energy, 16 kHz, 256-sample hop — 0.77 s of audio) and returns three outputs:
| output | shape | meaning |
|---|---|---|
root_logits |
13 | 12 pitch classes + "Noise" |
quality_logits |
11 | maj, min, maj7, dom7, min7, m7b5, dim7, aug, sus, note, N |
pitch_logits |
12 | sigmoid — which pitch classes are sounding |
"Sounding" includes a string ringing on, one resonating in sympathy, and the note before — all of them true and none of them played just now. What was actually struck is the strike model's question, below.
CNN with Squeeze-and-Excitation blocks, then a Transformer encoder with a CLS token. 7.3M parameters, CPU inference.
Results
Measured on a validation split grouped by source recording, with solo tracks excluded:
| metric | |
|---|---|
| root accuracy | 98.1% |
| pitch F1 | 0.909 |
| exact match (root and quality) | 92.4% |
The strike model
The recognition model sees 0.77 s at a time and is asked every 40 ms; that is too coarse to tell whether a note that is already ringing was just struck again. The strike model answers only that question, on every 16 ms hop:
input short_features |
[batch, 770, time] — two Hann windows of the newest audio (1024 and 2048 samples at 16 kHz), magnitudes up to 4 kHz, ln(1 + 1000·a) / ln(1001) |
output onset_logits |
[batch, 12, time] — sigmoid per pitch class: struck at this frame |
| context | causal; 34 past frames plus the current one (0.56 s) |
| metadata | onset_threshold = 0.9, onset_history_frames = 34 |
A projection of the spectra and of their rise against the previous four frames, then four residual causal convolutions (dilations 1, 2, 4, 8). 260 thousand parameters; 0.7 ms per hop on a CPU.
It was trained as a branch beside the frozen recognition network and is cut out of that combined file, so it does not run the chord network on every hop. The branch never reads the chord input: its answer is identical to the last digit whatever the other input is.
The app uses it for everything that depends on what was struck rather than what is sounding: "Credit only what was struck" in the note modes (a class may be credited only if the model reported it struck in the last 0.35 s), a chord asked for twice in a row (it needs a fresh strike), and repeats — a note credited once counts again only when that pitch class has been struck since, not when it is merely still sounding. The app evens out the input level before the model and ignores a second firing of the same class within 0.6 s. Measured on every reviewed note of a labelled recording, spliced into new signals (the note alone, ringing out, and struck again with the pick stopping the old vibration):
| without the strike model | with | |
|---|---|---|
| a repeat allowed while the note only rings | 24 / 51 | 0 / 51 |
| struck again after 0.8 s, counted in time | 36 / 51, 11 early | 48 / 51, none early |
| struck again after 1.2 s, counted in time | 35 / 51, 14 early | 50 / 51, none early |
| a note ringing into the next chord, credited there | 47 / 51 | 0 / 51 |
Training data
GuitarSet whole takes (solo and comp, players split whole: 00–03 train, 04 validation, 05 test), Karplus–Strong synthetic plucks with exact attack times (holds, re-plucks of a ringing note, octaves, an added third or fifth, re-struck triads), and masking pairs: a quieter upper note struck over two ringing ones at −18, −12, −6 or 0 dB, each with its background alone and itself alone. Levels vary by ±6 dB in training.
Training
Each model has its own trainer in dist/ of the GitHub repository, one file to
paste into a Kaggle GPU notebook: model_trainer.py for the recognition model
(it writes best_model_v2_take6_chords.onnx), strike_trainer.py for
the strike model, whose defaults are the recipe of short_onset_masking_v2.onnx.
See docs/training.md there.
Using it
Put the files next to the Solitito binary; the release packages already
contain them. SOLITITO_MODEL points the app at another recognition model
file. The strike model is optional: without it the app still
starts and judges repeats on a pitch-blind attack detector. ./solitito --check verifies
what is there and prints the strike model's threshold.
Feeding these models your own features requires matching the DSP exactly — the
input is not raw audio. For the recognition model, dist/gen_weights.py in the
GitHub repository produces the kernel, and dsp_weights.json here is its output.
For the strike model, src/strike.rs (ShortFeatures) and the trainer compute
the same features, and a shared test fixture holds them to the same numbers.
Training data of the recognition model
Two sources: a synthetic set rendered through NAM amp models with exact labels, and GuitarSet for real playing.
Getting GuitarSet right took four runs. Half of it is _solo — monophonic
improvisation carrying the accompaniment's chord annotation — and its
instructed chord labels contain no maj7 or min7 at all, while calling 500
segments m that were played as m7. Fixing those two moved exact match from
44.8% to 92.4%. The details, with numbers, are in the GitHub README.
License
MIT. GuitarSet is CC BY 4.0 — Qingyang Xi, Rachel M. Bittner, Johan Pauwels, Xuzhou Ye & Juan P. Bello, https://guitarset.weebly.com/.
